Tapered Roller Bearing

580/572 Bearing SET401 Tapered roller Bearing 580 – 572

size:82.55*139.982*35.253mm
weight:2.2kgs
Grade:P5
Material: Gcr15
Description:
INQUIRY EMAIL

580/572 Bearing Specification:

580/572 bearing is imperial taper roller bearing.
For this bearing,
Cone Number: 580
Cup Number: 572
Mass: 2.14kg/set
d – Bore: 82.550 mm/3.2500 in
D – Outer Diameter: 139.982 mm/5.5111 in
T – Bearing Width: 35.253 mm/1.3879 in
Bearing Material: Chrome steel, Gcr15
Cage Material: Standard stamped steel
Cross Reference: 580/572, 580 – 572, 580 – 572A, SET401, SET 401 and so on

Imperial Taper Roller Bearings Size Chart:

Model Number	Dimensions (mm)	Mass (kg)
HM516448/HM516410	82.550×133.350×39.688	2.140
HM516449A/HM516410	82.550×133.350×39.688	2.100
HM516449C/HM516410	82.550×133.350×39.688	2.150
495/493	82.550×136.525×30.162	1.610
580/572X	82.550×139.700×36.512	2.110
582/572X	82.550×139.700×36.512	2.070
580/572	82.550×139.982×35.253	2.140
580/574	82.550×139.992×36.512	2.140
582/572	82.550×139.992×36.512	2.100
47685/47621	82.550×139.992×36.512	2.130
47686/47621	82.550×139.992×36.512	2.120
580X/572	82.550×139.992×36.512	2.120
HM617045/HM617010	82.550×142.138×42.862	2.770
663/653	82.550×146.050×41.275	2.730
663A/653	82.550×146.050×41.275	2.700
595/592XE	82.550×147.638×35.717	2.590
595/592XS	82.550×147.638×35.717	2.570
595/593X	82.550×150.000×35.992	2.710
749A/742	82.550×150.089×44.450	3.350
